Cadences

Cadences are perhaps the most important and most musically impactful movements in pibroch. I would go further to state: they are the most expressive embellishment in all of bagpipe music.

Modern Cadence

The modern cadence is a tool of expression which, in the hands of a creative musician, can bring a sense of flair and grace to a tune.  It is a movement whose presence in the tune should act as a supplement to the melody, adding (sometimes considerably) to the timing of the ensuing phrase which it introduces.

There are several different forms and names given this movement.  According to Andrew Wright, General Principals of Piobaireachd (ch 7: 16-18; ch 10: 28-30), we have:

  • the “single-note cadence” used to introduce  a lower (non-embellished, non-grace noted) note;

Screen Shot 2014-06-13 at 4.10.08 PM

  • the three-note “step-down” cadence (“These are not connecting notes, but melody notes forming part of the phrase”)

Screen Shot 2014-06-13 at 4.09.54 PM

  • the “step-up” cadence (preceding a note at the end of a phrase that is higher up in the scale), and

Screen Shot 2014-06-13 at 4.09.41 PM

  • the five-note “run-down” cadence (descending from E, D, B A and ending on G)

Screen Shot 2014-06-13 at 4.09.27 PM

Setting aside the subtle and important nuances and differences between them that he elaborates, what every single one of those cadences have in common is the prominence of the high E in the series.  In every case, the E is given rhythmic priority in the run, whether significantly or just as a slight pause before descending.  This is called appoggiatura – a classical music term that David Glen mentions.

Screen Shot 2014-06-02 at 12.59.18 PM

For this reason, that is, because of the prominence of the high E in the movement, the cadence is known generally as the “E cadence”. And, generally speaking, every cadence in modern pibroch is an “E cadence”, even when it is argued that there are subtle differences.  There’s just no escaping it: the high E dominates the movement.

The appoggiatura cadence, in fact, is the only form of expression performed today.

The Murkier History of Cadences

Now, the very respectable and famous piper and law scholar James Campbell (from Pembroke College; a member of the music committee and honorary president of the Piobaireachd Society) published what he considered to be his most satisfying work, “The Elusive Appoggiatura” in The Piping Times.  In it, he argues that the modern form of the cadence (the appoggiatura) was, in fact, the same throughout pibroch performance history as it is today.  Looking through the primary source material this may not be obvious, but nevertheless, pipers did not play what was written, but favored the appoggiatura nonetheless.

Now, this is a very interesting argument.  It is, in essence, an effort to argue for the historical and traditional roots of our modern practice.  Which would be a comfort to performers, certainly: You could feel confident that what you are hearing today is what was always played.

Only, you’d be mistaken.

Setting aside the clearly apologetic interest on the part of Campbell to defend his own editorial agenda, there are two problems with his argument.

First, the appoggiatura is clearly known and written by primary source transcribers when they confronted it in a performance.  In other words, primary sources knew when they heard an appoggiatura cadence and they wrote what they heard.  So, when they didn’t write it, it was because they heard something else.

For example, let’s take a look in Hannay-MacAuslan.  Here’s an example of an appoggiatura cadence:

Screen Shot 2014-06-13 at 12.43.10 PM

Or let’s take a look  in Peter Reid:

Screen Shot 2014-06-13 at 12.41.54 PM

So, clearly the primary source transcribers knew how to write an appoggiatura.  One would have a difficult time, therefore, arguing that every cadence was written one way, but played differently: that is was merely a “custom” to write the cadence with three 32nd (or 64th) notes in a row. If there was a custom in notation, it could be more fairly argued that something like this would be it:

Screen Shot 2014-06-13 at 12.52.30 PM

Why would a transcriber write a full cadence down to D in front of a melody D note?  That’s impossible to play. How can we explain it?  Quite simply, actually: the transcriber was habituated to writing a cadence with 3 notes, and simply wasn’t thinking. But just as clearly s/he was not writing an appoggiatura cadence, or else it would have been written differently: at the very least, the run would have ended on an E (pride of place), or the E would have been written as a melody note.

Second, Campbell’s argument is limited to a three note cadence. That’s all he was concerned with, and limited his evidence for the predominance of the appoggiatura strictly to it.

But if pibroch players always held the high E, what did they do when they encountered this?:

Screen Shot 2014-06-11 at 8.44.39 PM

Here is run of four notes.  This type of run can be found in MacArthur-MacGregor (e.g. PS 17 – Daughter’s Lament), MacDonald (e.g. PS 30 – Glengarry’s March) and Reid (e.g., above) manuscripts.  It is written in the same rhythmic pattern as the three-note run.  How are we to interpret the rhythm of the four note run, if the three-note run isn’t supposed to be played as transcribed?  If the transcriber did not mean to write three notes of equal length, did she or he not mean to write four notes of equal length?  If that were true, how would the four-note run sound?

One of the principles to adopt as a Modern Traditional Piper is that the primary source manuscripts and scores were trying to be as descriptive as possible when representing performance.  Clearly, there is room for discussion about this point: Baroque and classical music was, by definition, more flexible than the rhythmic system of musical notation could capture.  Nevertheless, notating bagpipe music was new at the time, and customs of notation had not had a chance to get to the point where someone could say (like they do today all of the time), “Well, yes, I know it looks like you play it that way, but actually you play it this other way.”

Now, let’s be clear: once notation systems took hold, a change took place in the music.  This must happen – the shift from orality to literacy is a shift away from tonality.  It happens in every language system, whether we are talking about words on a page or notes on a score.  At some point, editorial choices are made.

In other words, there is an element of the  prescriptive in every transcriber’s choice of notating a song.  This is perhaps nowhere more clearly seen than in Angus MacKay’s book.  Here he made a studious effort to codify pibroch tunes according to his specific stylistic requirements. That’s not so bad, really.  But what is rather sad is he did so by eliminating a significant number of movements, and by standardizing all the rest. And among those movement he prescribed for standardized performance was a specific style of cadence: regularly, universally and consistently notated without exception or reference to any other type:

Screen Shot 2014-06-13 at 1.13.34 PM

All cadences became appoggiatura.  Even when the E of the cadence was not given so much significance as to warrant a full melodic note in the line, the typesetting continued to indicate its relative importance compared to the rest of the notes:

Screen Shot 2014-06-13 at 2.19.37 PM

In comparison, evidence of Reid, like we saw above, indicates a couple of ways in which a cadence may be played.  And if you look at other sources, you’ll see an overwhelming and unexpected variety:

Screen Shot 2014-06-11 at 8.37.15 PM Screen Shot 2014-06-11 at 8.36.44 PM Screen Shot 2014-06-11 at 8.37.52 PM Screen Shot 2014-06-11 at 8.38.08 PM Screen Shot 2014-06-11 at 8.38.31 PM Screen Shot 2014-06-11 at 8.38.37 PM Screen Shot 2014-06-11 at 8.42.47 PM Screen Shot 2014-06-11 at 8.41.13 PM



How to Play Cadences

Here at the Alt Pibroch Club, we identify up to four different ways in which a cadence has been and may be played. These are styles of performance, rather than length of cadence per se.

Begin learning an urlar by NOT playing ANY of the cadences notated in the score.  This will allow you the opportunity to hear the actual melody, that foundation of music that the cadences are meant to supplement and enhance.



Then, consider employing any combination of these four styles of cadences:

First, there is the simple high G.  Campbell Canntaireachd uses a single notational vocable for all cadences: “hi” (pronounced “hee”). It can represent any of the styles we mention here, including a simple high G.

Second, there is the “held” cadence. There are two kinds: a two-note (which may or may not include a high E – notice in the examples above that there are high Fs that could be held!), and a three-note.  This is the appoggiatura cadence, where the second note is used for effect before moving onto the rest of the cadence or onto the melody note.  It is very powerful, but can tend to dominate to the point that it takes away from the tune.

Third, there is the “tripping” cadence (Wright’s “step-down”).  This is a three-note cadence where the middle E is held slightly longer than the other notes, just long enough to be more prominent.

Fourth, there is the “streaming” cadence.  This idea comes from the Gaelic term in the harping world of the time for a similar expression, known as  “sruth”.   Its rhythm (as seen particularly in MacDonald’s and Reid’s collections) is that of a “trickling stream” – each grace note given equal weight, the movement itself beginning on the beat.

Screen Shot 2014-05-27 at 4.22.11 PM   Screen Shot 2014-05-27 at 4.20.22 PM  Screen Shot 2014-05-27 at 4.21.28 PM

The result is a lovely “waterfall”-like sound, comprised of 2, 3 or up to 4 grace notes landing on the theme note.

It may prove of value and interest to the performer, for the sake of experiencing the difference brought to a tune when performing the “stream” cadence, to play these two versions of Young George one after the other:

From MacKay (Appoggiatura) – Screen Shot 2014-06-13 at 3.44.47 PM

And this from MacDonald (stream – do not hesitate on the E; play all notes big – like a trickling sound and on the beat) –

Screen Shot 2014-06-13 at 3.45.59 PM

The function of the “cadence” in pibroch is to bring emphasis to the theme note and melody.

The Modern Traditional Piper will find it a valuable extension of her or his performance to re-introduce the “trickling” and  “stream” into her or his repertoire, combining it with the appoggiatura, single note and “tripping” (or “step-down”) cadences throughout the Urlar.  The result will be an enrichment of musical expression available to the performer (and listener, when done well).

To hear the different styles side by side gives the listener an opportunity to note very distinctive differences to a tune, as a new kind of dimension to the melody is created through the use of the “trickling-stream” cadence.

With this in mind, you now have available to you the most expressively powerful movement in all bagpiping performance. Use it wisely to bring out the beauty and subtlety of the Urlar.

Return to Modern Traditional Pibroch.
